316 Stainless Steel Coil Supplier

Supported by incredible industry experience and inside and out market space, we are engaged with providing and exchanging 316 Stainless Steel Coil. Proficiently produced by our deft specialists with the guide of dynamic hardware, this steel loop is open in changed measurements according to the particular requests of the clients. These curls can found in numerous forms surface completes, sizes, and sizes. Treated steel curl 316 offered a more grounded protection from erosion, magnificent temperature obstruction, and made it proper for various applications. This evaluation is commonly the most generally utilized evaluation of treated steel. It offers a superior chloride-safe pitting and hole. The 316 likewise has a tractable, crawling and stress breakage quality and high welding and formability. Utilized in Food Industries, Chemical Industries , Electrielcal Industries, Genrater Industries, Shaft Industries, Cement Industries, Gas Industries, Power Project and so on..

Enquiry Now

Product Specifications
Item	stainless steel 316 Coil
Standard	JIS, ASTM, AISI, GB, EN, DIN
Surface	2B, BA, HL, No. 4, Mirror etc.
Finish	cold rolled, hot rolled
Thickness	0.3mm--100mm
Size	1000mm, 1219mm, 1250mm, 1500mm, 1524mm, 2000mm
Application	household products, ships building industry, petroleum & chemical industries, food processing and medical industry, machinery and hardware fields, etc.

Stainless Steel 316 Grade Specification

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
316	S31600	316S31	58H, 58J	1.4401	X5CrNiMo17-12-2	2347	SUS 316

Chemical Properties Of 316 Stainless Steel Coil:

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316	Min	-	-	-	0	-	16.0	2.00	10.0	-
316	Max	0.08	2.0	0.75	0.045	0.03	18.0	3.00	14.0	0.10

Mechanical Properties Of 316 Stainless Steel Coil:

Grade	Tensile Str (MPa) min	Yield Str 0.2% Proof (MPa) min	Elong (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
316	515	205	40	95	217

Physical Properties Of 316 Stainless Steel Coil:

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Co-eff of Thermal Expansion (µm/m/°C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100°C (J/kg.K)	Elec Resistivity (nΩ.m)
			0-100°C	0-315°C	0-538°C	At 100°C	At 500°C
316	8000	193	15.9	16.2	17.5	16.3	21.5	500	740
